Specifications
| Ports | Full Port |
|---|---|
| Body Style | Three-Piece Direct Mount |
| Size Range | 1⁄4“–4″ |
| Temperature Range | -20 °F–450 °F |
| Pressure Ratings | 1000 PSI MAWP/WOG |
| End Connections | Threaded or Socket Weld |
| Body Materials | CF8M, 316SS |
| Seat Materials | PTFE/PRPTFE/TFM-1600 |
| Applications | Cost effective for most industrial applications |
| Flo-Tite’s Standard Part Numbers | DM310-SS-1-TTT-L DM320-SS-2-TTT-L |
