Specifications
| Body Style |
Lug Body with Two Piece Stem Design |
|---|---|
| Size Range |
2″ -36″ |
| Temperature Range |  |
| Pressure Ratings |
2″ -12″ – 200 WOG – Bi-Directional Flow 14″ – 24″ 175 WOG – Bi-Directional Flow 250 WOG -Uni-Directional Flow -OPTIONAL |
| Handle or gear operator dimensions |  |
| Body Materials | Ductile Iron with High Quality Epoxy Coating |
| Seat Materials |
Buna-N (NBR), EPDM, Viton, Neoprene, Hypalon, Silicon, PTFE |
| Applications |
Ideal Butterfly Valve for Automation and Demanding Manual Applications offering longer service life, greater reliability, ease of parts replacement, and interchangeability of components. |
