Specifications
| Body Style |
Wafer Body with Two Piece Stem Design |
||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Size Range |
2″ -36″ |
||||||||||||||||
| Temperature Range |
Seat Temperature Range
|
||||||||||||||||
| Pressure Ratings |
2″ -12″ – 200 WOG – Bi-Directional Flow 14″ – 24″ 175 WOG – Bi-Directional Flow 250 WOG -Uni-Directional Flow -OPTIONAL |
||||||||||||||||
| Handle or gear operator dimensions |  |
||||||||||||||||
| Body Materials | Ductile Iron with High Quality Epoxy Coating | ||||||||||||||||
| Seat Materials |
Buna-N (NBR), EPDM, Viton, Neoprene, Hypalon, Silicon, PTFE |
||||||||||||||||
| Applications |
Ideal Valve for Severe Service Applications where Precise Control is Required. Ideal for Clean or Dirty Liquids, Gases, and Fibrous Suspension Applications. |
