Specifications
| Ports | Standard Port/Reduced Port |
|---|---|
| Body Style |
One-Piece SF150/SF300 |
| Size Range |
SF150/SF300 1″–12″ |
| Temperature Range |
-20 °F–550 °F |
| Pressure Ratings |
150 SWP, optional 300 psig |
| End Connections | Flanged |
| Body Materials | 316 SS
WCB |
| Seat Materials |
TFM – Standard |
| Applications |
Ideal Design for Process and Petrochemical Applications |
| Flo-Tite’s Standard Part Numbers | F150-SS-FFG-L (150# SS – Standard FFG) F150-SS-FGG-L (150# SS – Fire Safe FGG) F150-SS-FFGN-L (150# SS – Standard FFGN Viton free) F150-SS-FGGN-L (150# SS – Fire Safe FGGN Viton free) F150-CS-FFG-L (150# CS – Standard FFG) F150-CS-FGG-L (150# CS – Fire Safe FGG) F150-CS-FFGN-L (150# CS – Standard FFGN Viton free) F150-CS-FGGN-L (150# CS – Fire Safe FGGN Viton free) F300-SS-FFG-L (300# SS – Standard FFG) F300-SS-FGG-L (300# SS – Fire Safe FGG) F300-SS-FFGN-L (300# SS – Standard FFGN Viton free) F300-SS-FGGN-L (300# SS – Fire Safe FGGN Viton free) F300-CS-FFG-L (300# CS – Standard FFG) F300-CS-FGG-L (300# CS – Fire Safe FGG) F300-CS-FFGN-L (300# CS – Standard FFGN Viton free) F300-CS-FGGN-L (300# CS – Fire Safe FGGN Viton free) C/F price may vary on viton-free items according to stock |
