Hi Tek Double Offset Butterfly Valve

Body Style	One Piece Lug, Wafer, and Flanged
Size Range	2″ – 110″
Temperature Range	150lb Double Offset Butterfly Valve: CS Body with PTFE Seat: -50°F to 400°F (-45°C to 204°C) CS Body with Metal Seat (SS or Inconel): -50°F to 1000°F (-45°C to 538°C) SS Body with PTFE Seat: -50°F to 450°F (-45°C to 232°C) SS Body with Metal Seat: -50°F to 1200°F (-45°C to 649°C) 300lb Double Offset Butterfly Valve: CS Body (WCB) with Metal Seat : -20°F to 800°F (-29°C to 427°C) SS Body (CF8M) with Metal Seat: -100°F to 1000°F (-73°C to 538°C) Inconel or Other Alloys: Up to 1200°F (649°C)
Pressure Ratings	ANSI Class 150300
Handle & Gear	150 LB – 2”- 4” Lever, 5” – 110” Gear 300LB – 2”- 4” Lever, 5” – 60” Gear
Body Materials	Standard –Carbon Steel, Stainless Steel Optional – Special Alloys : Titanium Nickel Monel Hastelloy Incoloy Inconel Zirconium Duplex Super Duplex
Seat Materials	PTFE RTFE MTFE
Applications	Petroleum & Oil Industry Coal Chemistry Organic Chemistry New Energy Environment Water Treatment
